About the SFX CAT6 UTP Eca LSZH 305m easy pull box

Product Description

Premium Category 6 UTP LSZH Network Cable

Our premium Category 6 un-shielded (UTP) low smoke and halogen free (LSZH) network cable is supplied in easy pull boxes of 305 metres and is clearly metre marked for easy cable identification.

The cable is tested to meet and exceed the Category 6 standard and is suitable for installation in densely populated buildings such as schools, offices and retail units where a halogen free cable is required for fire and building regulations.

Features

  • Easy pull 305 metre boxes
  • Solid coppers conductors
  • Clearly metre marked
  • Low smoke and halogen free sheath

Specification

General
Inner Conductor 23 AWG plain copper
Insulation High density polyethylene
Construction 4 twisted pairs cabled together with spline
Colour Code Pair 1:White/Blue-Blue/White
Pair 2:White/Orange-Orange/White
Pair 3:White/Green-Green/White
Pair 4:White/Brown-Brown/White
Jacket Low Smoke Zero Halogen
Overall Diameter 5.5 mm +/- 0.2 mm
Weight (Kg/Km) 39.1 (PVC/PE)/41.2 (LSZH)
Min Bending Radius Installation 50 mm
Min Bending Radius Installed 25 mm
Impedance 100 Ohm +/- 15 Ohm
Capacitance 5.6nF/100 m
DC Resistance 9 Ω/100 m
Velocity Ratio 69%
Operating Temperature Range -20°C to +60°C
Installation Temperature Range 0°C to +50°C
Conforms to ANSI/TIA-568-C Category 6 Specification
LSZH Jacket Conforms to IEC 60332-1, IEC 61034 and IEC 60754
