EASY INSTALLATION
The dogleg mounting system makes the install process an easy one-step action simply by tightening the dedicated screws to swing out the dogleg brackets.
WIDE DISPERSION
All speakers by DALI are designed around the principle of wide dispersion. This entails an off-axis optimisation of the audio reproduction. The technology is perfect for use in install speakers, since they are always mounted flush against either a wall or ceiling.
Product series | PHANTOM K-80 |
---|---|
Frequency Range (+/-3 dB) [Hz] | 52 - 25,000 |
Sensitivity (2,83 V/1 m) [dB] | 88.0 |
Nominal Impedance [ohms] | 8 |
Maximum SPL [dB] | 105 |
Recommended Amplifier Power [W] | 30 - 120 |
Crossover Frequency [Hz] | 3,300 |
High frequency driver, Quantity | 1 x 28 mm |
High frequency driver, Diaphragm type | Soft Textile Dome |
Low frequency driver, Quantity | 1 x 8" |
Low frequency driver, Diaphragm type | Wood Fibre Cone |
Enclosure type | Open back |
Recommended Working Volume | 10 - 100 L |
Connection Input | Single Wire |
Recommended Placement | In-Ceiling |
Functions | Focus / Distributed Normal / HF + Tilt |
Dimensions (ØxD) [mm] | 258 x 99.5 |
Cut-Out Dimensions (ØxD) [mm] | Ø225 |
Accessories Included | Cut-Out Template Logo Badge Manual Front Grille |
Optional Accessories | Square Grille |
Weight [kg] | 1.92 |
